CE-HM-R68 series
- Commodity name： CE-HM-R68 series
- Description
-
CE-HM-R68 Series Module Technical Specifications Serial Number Module Configuration Output Speed
(RPM)Rated Torque
(Nm)Peak Torque
(Nm)Backlash
(Arcsec)1 Mechanical Characteristics 51:1 60 13 38 15 2 101:1 30 26 75 15 3 Electrical Characteristics Rated Voltage
(V)Rated Power
(W)Rated Speed
(RPM)Rated Current
(A)Peak Current
(A)4 48 134 3500 3.8 12 5 Encoder Dual encoder, single-turn absolute value: 19-bit single turn 6 Driver Interface: EtherCAT/CAN, Current loop: 50KHz, Speed loop: 10KHz 7 Overall Size R68*66.3 mm 8 Overall Weight 0.8kg 9 Typical Applications Shoulder joint, elbow joint, knee joint
